Pin
Function
Dim
Description
1
DC plant supply
input (-ve)
2.5mm
System DC negative input.
(Battery Negative).
2
DC plant supply
input (+ve)
2.5mm
System DC positive input.
(Battery Positive).
(Recommended Maximum Fuse 20A)
3
Emergency stop
input
2.5mm
Plant supply +ve. Also supplies fuel &
start outputs.
4
Fuel relay output
1.5mm
Plant supply +ve from pin 3.
16 Amp rated.
5
Start relay output
1.5mm
Plant supply +ve from
pin 3.
16 Amp rated.
Connect to
starter starting
coil.
6
Auxiliary output
relay 1
1.5mm
Plant supply +ve from
pin 2.
7 Amp rated.
Reference
table 2
7
Auxiliary output
relay 2
1.5mm
Closed output,
7 Amp rated.
8
Relay common point
9
Open output,
7 Amp rated.
10
Auxiliary output
relay 3
2.5mm
Free volt contacts.
16 Amp rated
11
12
Auxiliary output
relay 4
2.5mm
13
14
Charge fail / excite
1.0mm
Do not connect to ground (battery –ve)
