HGM6000K Series Automatic Generator Module ISSUE 2011-06-20 Version 1.7 Page 27 of 34
Num
Content
Remark
5 CURTIS
6 DATCON 10Bar
7 VOLVO-EC
8 SGX
3
Fuel level
Sensor
0 Not used
1 Defined RT
2 SGH
3 SGD
4 Reserved 1
5 Reserved 2
Defined input
resistance range is
0-999.9 ohm, factory
default is SGD
7.5 CONDITION OF CRANK SUCCEED (TABLE 5)
Num
Content
0
Magnetic sensor
1
Genset
2
Magnetic sensor+Genset
3
Magnetic sensor + Oil pressure
4
Genset + Oil pressure
5
Genset+Magnetic sensor + Oil pressure
1． The crank disconnect condition has three kinds, the magnetic pickup sensor
and the genset voltage can be used alone, the oil pressure must be used with
the magnetic pickup sensor and the genset voltage, the purpose is to make
the starter and the engine to disconnect as soon as possible.
2． Magnetic pickup sensor is installed in the engine block number of magnetic
device testing flywheel.
3． When choosing magnetic pickup sensor, ensure engine flywheel teeth setting,
otherwise may appear over speeding shutdown or loss speed shutdown.
4． If the genset is not magnetic pickup sensors, please don't choose
corresponding, otherwise this will occur fail to start or loss of speed alarm and
shutdown.
5． If the genset has no oil pressure sensor, please don't choose corresponding.
6． If the genset starting conditions has not be selected, the controller will not
measure and display the relative parameters (This can be applied to the pump
set), if not choose magnetic pickup sensor, the speed signal will come from
the generating AC signal.
