HGM6000K Series Automatic Generator Module
HGM6000K Series Automatic Generator Module ISSUE 2011-06-20 Version 1.7 Page 14 of 34
in excess of the setting value a shutdown is initiated. At the same time LCD
screen flicker.
GENSET UNDER FREQUENCY, if the module detects a genset output frequency
below the setting value after the Safety On timer has expired, a shutdown is
initiated. At the same time LCD screen flicker.
GENSET OVER VOLTAGE, if the module detects a genset output voltage in
excess of the setting value a shutdown is initiated. At the same time LCD screen
flicker.
GENSET UNDER VOLTAGE, if the module detects a genset output voltage
below the setting value after the Safety On timer has expired, a shutdown is
initiated. At the same time LCD screen flicker.
GENSET OVER CURRENT, if the module detects a genset output current in
excess of the setting value is initiated, a shutdown is initiated. At the same time
LCD screen flicker.
FAIL TO START, if
the
engine does not fire after the pre-set number of attempts
has been made a shutdown will be initiated. At the same time LCD screen
flicker.
AUXILIARY INPUTS, if an auxiliary
input
has been configured as a shutdown the
appropriate information will be displayed. At the same time LCD screen
flicker.
NO GENSET ALARM SHUTDOWN, when the controller detects to genset
frequency equals to zero, the controller sends out the shutdown alarm signal. At
the same time LCD screen flicker.
TEMPERATURE SENSOR OPEN CIRCUIT, when the controller detects to
temperature sensor open circuit, the controller sends out the shutdown alarm
signal. At the same time LCD screen flicker.
OIL PRESSURE SENSOR OPEN CIRCUIT, when the controller detects to oil
pressure sensor open circuit, the controller sends out the shutdown alarm signal.
At the same time LCD screen flicker.
6 CONNECTING TERMINAL
HGM6010KC compared with HGM6020KC, is less a Mains three phase AC input
terminal. The HGM6010KC and HGM6020KC backplane is as following.
