HGM6000K Series Automatic Generator Module ISSUE 2011-06-20 Version 1.7 Page 17 of 34
Pin
Function
Dim
Description
40
Common port
1.0mm
Auxiliary input common port
Note:
1. These terminals of 31, 32, 33, and 34 are not used for HGM6010KC
module.
2. Back LINK interface as a parameter programming interface, used by SG72
adapter PC controller programming.
7 PARAMETER RANGE AND DEFINE
All parameters of HGM6000K series as follows:
Note: small brackets set item number 6010KC.
7.1 PARAMETERS TABLE (TABLE 1)
Num
Parameter
Range
Default
Remark
P 01
Mains volt
normal delay
(0-3600)s
10
Mains transient delay,
suited for ATS(automatic
transfer switch)
P 02
Mains volt
abnormal
delay
(0-3600)s
5
P 03
Mains under
volt
(30-360)V
184
When mains voltage is
under than the point, mains
under voltage are active.
When the point is zero,
mains under voltage are
disabled.
P 04
Mains over
volt
(30-360)V
276
When mains voltage is over
than the point, mains over
voltage are active. When
the point is 360V, mains
over voltage are disabled.
P 05
Transfer
switch interval
(0-99.9)s
1.0
It‟s the delay from mains is
opened to genset closing or
from genset is opened to
mains closing.
P 06
(P01)
Start delay
(0-3600)s
1
It‟s the delay from remote
start signal is active or
mains is failure, to start
genset.
P 07
(P02)
Stop delay
(0-3600)s
1
It‟s the delay from remote
start signal is inactive or
mains is normal, to stop
genset.
