Displaying Connection Status
Use the Port Status page to display the current connection status, including
link state, auto-negotiation, speed/duplex mode, and flow control.
Field Attributes
• Type – Shows port type as:
- 10/100TX 10BASE-T / 100BASE-TX
- 100FX: 100BASE-FX
• Enabled – Shows if the port is enabled or disabled.
• Status – Indicates if the link is Up or Down.
• Mode – Shows the port speed and duplex mode.
• Flow Control – Indicates the type of flow control in use.
Console – Click Status and Counters
=>
Port Status.
Tiger Switch 10/100 6709FL2 : Port Status
===========================
Port Type Enabled Status Mode FlowCtrl
---- -------- ------- ------ --------- --------
1. 10/100TX No Down 100 Full On
2. 10/100TX Yes Up 100 Full Off
3. 10/100TX No Down 100 Full On
4. 10/100TX No Down 100 Full On
5. 10/100TX No Down 100 Full On
6. 10/100TX Yes Up 100 Full Off
7. 10/100TX No Down 100 Full On
8. 10/100TX Yes Up 100 Full Off
9. 100FX No Down 100 Full On
actions-> <Quit>
Select the action menu.
Tab=NextItem BackSpace=Previous Item Quit=Previous menu Enter=Select Item
