C ONSOLE I NTERFACE
4-20
VLAN Configuration Menu
Use the VLAN Configuration menu to specify the VLAN type used on
this switch, configure VLAN groups, or set the default VLAN identifier
and ingress filtering for each port.
Tiger Switch 10/100 6709FL2 : VLAN Configuration
===========================
VLAN Configure
Create a VLAN Group
Edit/Delete a VLAN Group
Previous Menu
Configure the VLAN PVID and Ingress Rule.
Tab=Next Item BackSpace=Previous Item Quit=Previous Menu Enter=Select Item
Menu Description Page
VLAN Configure Sets port VID and ingress filters 4-21
4-23
Create a VLAN Group Configures VLAN groups, including name,
identifier, and if limited to a specific protocol
4-21
4-23
Edit/Delete a
VLAN Group
Modifies VLAN groups, including name,
identifier, and if limited to a specific
protocol; or deletes a specified group
