Specifications
Appendix
A-2 Appendix
Analog component output
Bandwidth
Y DNW-A100/A50/A45: 0 to
4.5 MHz +0.5 dB/ –3.0 dB
DNW-A100P/A50P/A45P: 0 to
5.5 MHz +0.5 dB/ –3.0 dB
R–Y/ B–Y 0 to 2.0 MHz +0.5 dB/–3.0 dB
S/N ratio 56 dB or more
K factor (2T pulse)
1% or less
Analog component input to component output
Input A/D quantization
8 bits/ sample
Bandwidth
Y DNW-A100/A50/A45: 0 to
4.5 MHz +0.5 dB/ –3.0 dB
DNW-A100P/A50P/A45P: 0 to
5.5 MHz +0.5 dB/ –3.0 dB
R–Y/ B–Y 0 to 2.0 MHz +0.5 dB/–3.0 dB
S/N ratio 52 dB or more
K factor (2T pulse)
1% or less
LF non-linearity 3.0% or less
Analog composite input to analog composite
output (with optional BKDW-505 for DNW-
A100/A50/A45 or BKDW-506 for DNW-A100P/
A50P/A45P)
Bandwidth (Y) DNW-A100/A50/A45: 0 to
4.5 MHz +0.5 dB/ –3.0 dB
DNW-A100P/A50P/A45P: 0 to
5.5 MHz +0.5 dB/ –3.0 dB
S/N ratio 53 dB or more
Differential gain 2% or less
Differential phase 2° or less
Y/C delay 15 ns or less
K factor (2T pulse)
1% or less
Output SCH phase
Based upon RS-170A/CCIR
R.624-3
Digital audio system
Digital audio (CH-1 to CH-4) signal format
Sampling frequency
48 kHz (synchronized with video)
Quantization 16 bits/ sample
Wow and flutter Below measurable level
Headroom 20 dB (or 18 dB, selectable)
Emphasis T1= 50 µs, T2=15 µs (on/off
selectable in recording mode)
Analog output
A/D, D/A quantization
16 bits/sample
Frequency response
20 Hz to 20 kHz +0.5 dB/ –1.0 dB
(0 dB at 1 kHz)
Dynamic range 90 dB or more (at 1 kHz, emphasis
on)
Distortion 0.05% or less (at 1 kHz, emphasis
on, reference level (+4 dBm))
Crosstalk –80 dB or less (at 1 kHz, between
any two channels)
