Sony FWD-42PV1 User Manual

45 (GB)
Specifications
Specifications
Video processing
Preset signal See page 25 (GB).
Sampling rate 13.5 MHz to 140 MHz
Panel system AC-type Plasma Display Panel
Display resolution 1366 dots
(horizontal) × 768 lines
(vertical)
FWD-42PV1/42PV1A:
Pixel pitch 1.08 (horizontal)
× 1.08 (vertical)
mm (
1
⁄16 ×
1
⁄16 inches)
Picture size 920 (horizontal)
× 518 (vertical)
mm (36
1
⁄4 × 20
1
⁄2 inches)
Panel size 42-inch (diagonal 1056 mm)
FWD-42PV1P:
Pixel pitch 1.08 (horizontal)
× 1.08 (vertical)
mm (
1
⁄16 ×
1
⁄16 inches)
Picture size 518 (horizontal)
× 920 (vertical)
mm (20
1
⁄2 × 36
1
⁄4 inches)
Panel size 42-inch (diagonal 1056 mm)
Inputs and Outputs
INPUT1
DVI DVI (DVI Specification Rev. 1.0
compliant)
AUDIO Stereo minijack (×1)
500 mVrms, high impedance
INPUT2
RGB/COMPONENT
D-sub 15-pin (female) (×1) (See
“Pin assignment” on page 46
(GB).)
AUDIO Stereo minijack (×1)
500 mVrms, high impedance
CONTROL S IN/OUT Minijack (×2)
AUDIO OUT Pinjack (×2)
500 mVrms, high impedance
REMOTE (RS-232C)
D-sub 9-pin (×1)
VIDEO/S VIDEO input/output adaptor
BKM-FW10 (only for the FWD-42LX1/
32LX1)
VIDEO (NTSC, PAL, SECAM, NTSC4.43,
PAL60, PAL-M, PAL-N)
1)
VIDEO IN BNC (×1)
Composite video, 1 Vp-p ±2 dB
sync negative, 75 ohms
(automatic termination)
VIDEO OUT BNC (×1) Loop-through
S VIDEO IN Mini DIN 4-pin (×1)
Y (luminance): 1 Vp-p ±2 dB sync
negative, 75 ohms terminated
C (chrominance): Burst
0.286 Vp-p ±2 dB (NTSC),
75 ohms terminated
Burst 0.3 Vp-p ±2 dB (PAL),
75 ohms terminated
S VIDEO OUT Mini DIN 4-pin (x1) Loop-through
AUDIO IN Pinjack (×2)
500 mVrms, high impedance
SPEAKER 7 W + 7 W (6 ohms), direct
unbalanced impedance:
6-16 ohms
General
Power requirements
100 V to 240 V AC, 50/60 Hz,
FWD-42PV1/42PV1P/42PV1A:
3.5 A (Maximum)
Power consumption
FWD-42PV1/42PV1P/42PV1A:
260 W
Operating conditions
Temperature: 0 °C to +35 °C
(32 °F to 95 °F)
Humidity: 20% to 90%
(no condensation)
Atomospheric pressure:
FWD-42PV1/42PV1P: 800 to
1100 hPa
Storing/transporting conditions
Temperature: –10 °C to +40 °C
(14 °F to 104 °F)
Humidity: 20% to 90%
(no condensation)
Atomospheric pressure:
FWD-42PV1/42PV1P: 700 to
1100 hPa

Sony FWD-42PV1 Specifications

General

Depth	121 mm
Width	1033 mm
Height	631 mm
Weight	29000 g
HD type	Not supported
I/O ports	-DVI-HDCP; Audio In -D-sub 15-pin (RGB / YUV), DIV; Audio In Remote (RS-232C) D-sub 9-pin, Audio Out, Control S In/Out; -S-Video In / Out; Audio In, Composite In Yes, Composite Out
Audio system	Surround (Off / Hall / Simulated)
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
Display diagonal	42 \
Display brightness	50 cd/m²
Display resolution	852 x 480 pixels
Display technology	Plasma
Power requirements	100 - 240V, 50/60Hz (3.5A max)
Contrast ratio (typical)	-
Display number of colors	1.073 billion colors
Storage temperature (T-T)	-10 - 40 °C
Analog signal format system	NTSC, PAL, SECAM
Operating temperature (T-T)	0 - 35 °C
Power consumption (typical)	260 W
Operating relative humidity (H-H)	20 - 90 %
