Sony HCD-HDX285 User Manual

HCD-HDX285/HDX287WC/HDX585/HDX587WC/HDX589W/HDX685/HDX686W
12
3-3. S-AIR-CON BOARD (HDX285/HDX585/HDX685)
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE (DCY)

two screws
(case 3 TP2)

case (DCY)

five screws
(BV/RING)



two screws
(case 3 TP2)

two screws
(BV3 (3-CR))

two screws
(BV3 (3-CR))

two screws
(BV3 (3-CR))

wire (flat type) (13 core)
(S-AIR-CON board: CN100,
MAIN board: CN306)
R
S-AIR-CON board

card slot
(S-AIR)

lid (S-AIR)

shield plate (S-AIR)

cord
(S-AIR-CON board: CN102,
POWER board: CN908)

cnnector
(CN101)
