HCD-HDX285/HDX287WC/HDX585/HDX587WC/HDX589W/HDX685/HDX686W
SECTION 8
ELECTRICAL PARTS LIST
ENCODER BOARD (Included in RELAY board)
***************
************************************************************
A-1602-528-A FL-JACK BOARD, COMPLETE
***********************
< CAPACITOR >
C5000 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C5002 1-124-584-00 ELECT 100uF 20% 6.3V
C5003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5004 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C5005 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C5006 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5007 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5008 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5009 1-119-772-91 ELECT 47uF 20% 35V
C5010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5011 1-126-157-11 ELECT 10uF 20% 16V
C5012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5020 1-126-157-11 ELECT 10uF 20% 16V
C5021 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5023 1-115-156-11 CERAMIC CHIP 1uF 10V
C5024 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C5025 1-124-584-00 ELECT 100uF 20% 10V
C5026 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C5027 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5028 1-124-589-11 ELECT 47uF 20% 16V
C5029 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5030 1-124-584-00 ELECT 100uF 20% 10V
C5031 1-124-261-00 ELECT 10uF 20% 50V
C5032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5035 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5036 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5037 1-124-261-00 ELECT 10uF 20% 50V
C5038 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5040 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C5041 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5042 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C5043 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C5044 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C5045 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5046 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5058 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5059 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5061 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5000 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN5001 1-779-554-21 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
< DIODE >
D5000 6-500-848-01 DIODE MC2840-T112-1
D5001 6-500-848-01 DIODE MC2840-T112-1
D5002 6-501-729-01 DIODE MAZ8051GLLS0
D5005 6-500-525-01 LED SLI-325YCT31W (DMPORT BOOSTER)
D5006 6-501-817-01 DIODE MA2J1110GLS0
D5007 6-500-848-01 DIODE MC2840-T112-1
D5008 8-719-060-48 DIODE RB751V-40TE-17
D5009 6-500-848-01 DIODE MC2840-T112-1
D5010 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB5000 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5001 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5002 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5003 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5006 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
< IC >
IC5000 6-704-470-01 IC TK11233CMCL-G
IC5001 6-713-497-01 IC HT16515
IC5002
6-600-349-21 IC NJL23H400A
IC5003 8-759-100-96 IC uPC4558G2
IC5004 8-759-100-96 IC uPC4558G2
< JACK >
J5000 1-822-262-11 JACK (AUDIO IN/A.CAL
MIC)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ENCODER
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
E3 : 240V AC area in E model
EA : Saudi Arabia model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
FL-JACK
To Next Page
