12
HCD-SC5/SC6/SC8
3-4. POWER BOARD
9
POWER board
4
screw
(+BV SUMITITE B3)
7
screw
(+BV SUMITITE B3)
6
two screws
(+BV SUMITITE B3)
3
connector (CN902)
2
connector (CN904)
1
connector (CN903)
5
power sheet
8
power sheet
3-5. I/O BOARD
4
connector (CN205)
(used only for AEP,UK and
Russian models)
2
wire (flat type)
(CN203)
5
wire (flat type)
3
wire (flat type)
(CN202)
7
two screws
(+BVTP 3
×
8)
1
five screws
(+BVTP 3
×
8
)
6
I/O board
8
tuner unit
