HCD-SC5/SC6/SC8
SECTION 6
DIAGRAMS
6-1. CIRCUIT BOARDS LOCATION
SCART board
(only for AEP, UK and Russian models)
AMP board
POWER board
POWER LED board
HP board
DVD board
DRIVER board
RF board
I/O board
DDCON board
FL board
LF board
