HT-CT380/CT381
6-4. MAIN BOARD SECTION
151 3-077-331-62 +BV3 (3-CR)
9 152 A-2076-756-A MAIN BOARD, COMPLETE (SV) (CT381)
(See Note 1)
9 152 A-2076-757-A MAIN BOARD, COMPLETE (SV)
(CT380: US, CND) (See Note 1)
9 152 A-2076-759-A MAIN BOARD, COMPLETE (SV) (CT380: AEP, UK,
E3, EA3,SP, AUS, PX) (See Note 1)
153 A-2063-682-A POWER BOARD, COMPLETE (US, CND)
(See Note 2)
153 A-2063-683-A POWER BOARD, COMPLETE (Except US, CND)
(See Note 2)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#4 7-682-546-09 SCREW +B 3X5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note 1: When the complete MAIN board is replaced, refer to “NOTE
OF REPLACING THE IC3001 ON THE MAIN BOARD AND
THE COMPLETE MAIN BOARD” and “NOTES ON THE
WIRELESS CONNECTION (LINK) AFTER REPAIRS ARE
COMPLETE” on page 5.
Note 2: When the complete POWER board is replaced, refer to “BOND
FIXATION OF ELECTRIC PARTS” on page 6.
#4
#4
#2
#2
#4
#4
not supplied
not supplied
not supplied
not supplied
not supplied
151
151
151
151
151
151
151
151
151
151
151
151
151
A
B
A
B
not supplied
not supplied
not supplied
not supplied
153
152
Ver. 1.1
To Next Page
