61
HT-CT380/CT381
SECTION 7
ELECTRICAL PARTS LIST
DISPLAY BOARD
*************
< CAPACITOR >
* C801 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C808 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C809 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
* C810 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C811 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C812 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
C813 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C814 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C815 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
C816 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C817 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C818 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C819 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C820 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C821 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C822 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C823 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C824 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C825 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN803 1-822-287-41 CONNECTOR, FFC/FPC 18P
CN804 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
< DIODE >
D802 6-502-961-01 DIODE DA2J10100L
D803 6-500-400-01 DIODE BAV99-215
* D804 6-503-578-01 DIODE RB520SM-30T2R
D805 6-500-400-01 DIODE BAV99-215
D806 6-502-241-01 DIODE KDZTR2.0B
D807 6-503-040-01 DIODE DZ2J300M0L
< IC >
IC801 6-600-767-01 IC PNA4823M02S0
IC803 6-719-198-01 IC MM3411A33URE
< COIL >
L801 1-481-524-11 INDUCTOR 10uH
< FLUORESCENT INDICATOR TUBE >
ND801 1-483-520-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q802 6-553-291-01 TRANSISTOR BC817DPN
< RESISTOR >
R801 1-218-937-11 METAL CHIP 47 5% 1/16W
R802 1-218-937-11 METAL CHIP 47 5% 1/16W
R803 1-218-937-11 METAL CHIP 47 5% 1/16W
R804 1-218-937-11 METAL CHIP 47 5% 1/16W
R805 1-218-941-81 METAL CHIP 100 5% 1/16W
R806 1-218-941-81 METAL CHIP 100 5% 1/16W
R807 1-218-941-81 METAL CHIP 100 5% 1/16W
R808 1-218-941-81 METAL CHIP 100 5% 1/16W
R810 1-216-809-11 METAL CHIP 100 5% 1/10W
R811 1-218-937-11 METAL CHIP 47 5% 1/16W
R812 1-218-937-11 METAL CHIP 47 5% 1/16W
R813 1-218-969-11 METAL CHIP 22K 5% 1/16W
R814 1-218-965-11 METAL CHIP 10K 5% 1/16W
R815 1-216-864-11 SHORT CHIP 0
R816 1-216-839-11 METAL CHIP 33K 5% 1/10W
R817 1-216-833-11 METAL CHIP 10K 5% 1/10W
R818 1-216-797-11 METAL CHIP 10 5% 1/10W
R819 1-216-797-11 METAL CHIP 10 5% 1/10W
R820 1-250-535-11 METAL CHIP 47K 1% 1/16W
*************************************************************
A-2063-684-A KEY BOARD, COMPLETE
*******************
When the KEY board is defective, replace the complete mounted board.
*************************************************************
9 A-2076-756-A MAIN BOARD, COMPLETE (SV) (CT381)
(See Note)
9 A-2076-757-A MAIN BOARD, COMPLETE (SV)
(CT380: US, CND) (See Note)
9 A-2076-759-A MAIN BOARD, COMPLETE (SV) (CT380: AEP, UK,
E3, EA3, SP, AUS, PX) (See Note)
********************
< CAPACITOR/JUMPER RESISTOR >
C1001 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
Note: When the complete MAIN board is replaced, refer to “NOTE OF REPLACING THE IC3001 ON THE MAIN BOARD AND THE COMPLETE
MAIN BOARD” and “NOTES ON THE WIRELESS CONNECTION (LINK) AFTER REPAIRS ARE COMPLETE” on page 5.
DISPLAY KEY MAIN
Ver. 1.1
