Operating a Single Camera Using the Optional Remote

Controller

What you can do with this system

Perform pan/tilt and zoom operations using the joystick of the remote controller.

System Configuration

Remote controller

Video monitor

Video signal

Remote Control (VISCA) signal

Signal flow
