Sony SRG-X40UH User Manual

52
SYSTEM SELECT switch settings
Video output format for the HDMI OUT/VIDEO
OUT terminal can be set with this switch.
*1 Outputs in the resolution after the EDID is set
on
the HDMI monitor.
The video signal does not output via USB
o
utput when 4K and the interlace output are
set.
Notes
• Be sure to set the switch before you turn on the
camera.
Turn on the power after you set the switch.
• Be sure to use a Phillips-head screwdriver
wh
en changing the switch position. If you use
a tool other than the designated screwdriver,
the crossed groove may be damaged.
Pin array of the VISCA RS-422
terminal and how to use it
Pin array of VISCA RS-422 terminal
Connection diagram with remote
controller RM-IP10
Notes
• Connect the GNDs of both devices together to
stabilize the voltage level of the signal.
• When preparing cables, use network cables of
cat
egory 5e or more and equivalent to or
higher than shielded twisted pair cables.
No.
Video output format/Frame rate
SRG-X40UH SRG-H40UH
HDMI
output
USB
output
HDMI
output
USB
output
0
3840x2160/
29.97p
Not
compatible
1920x1080/59.94p
1 1920x1080/59.94p 1920x1080/59.94p
2
1920x1080/
59
.94i
Not
compatible
1920x1080/
59.94i
Not
compatible
3 1920x1080/29.97p 1920x1080/29.97p
4 1280x720/59.94p 1280x720/59.94p
5 EDID *1 EDID *1
6 REMOTE REMOTE
7
720x480/
59
.94p
Not
compatible
720x480/
59.94p
Not
compatible
8
3840x2160/
25p
Not
co
mpatible
1920x1080/59.94p
9 1920x1080/50p 1920x1080/50p
A
1920x1080/
50i
Not
co
mpatible
1920x1080/
50i
Not
compatible
B 1920x1080/25p 1920x1080/25p
C 1280x720/50p 1280x720/50p
D Reserved Reserved
E Reserved Reserved
F Reserved Reserved
Select your desired
video output format.
Pin
No.
Function Pin
No.
Function
1 TX– 1 RX–
2 TX+ 2 RX+
3 RX– 3 TX–
4 GND 4 GND
5 GND 5 GND
6 RX+ 6 TX+
7 N.C. 7 N.C.
8 N.C. 8 N.C.
IN OUT
RM-IP10
1N.C.
2N.C.
3N.C.
4N.C.
5GND
6RX–
7RX+
8TX–
9TX+
Camera
1TX–
2TX+
3RX–
4GND
5GND
6RX+
7N.C.
8N.C.
Shield
