Sony SS-TSF500 User Manual

SA-WSF200/WSF500/SS-CTF500/F500/TSF200/TSF500
2
1. SERVICING NOTES ............................................. 3
2. GENERAL .................................................................. 7
3. DISASSEMBLY
3-1. Disassembly Flow (SA-WSF200/WSF500) ................... 8
3-2. Amp Complete Assy (SA-WSF200/WSF500) ............... 9
3-3. Loudspeaker (16 cm) (SP001)
(SA-WSF200/WSF500) .................................................. 9
3-4. Back Panel (WS) (SA-WSF200/WSF500) ..................... 10
3-5. Speaker Board, Terminal Board (WS)
(SA-WSF200/WSF500) .................................................. 10
3-6. AMP-DSP Board (SA-WSF200/WSF500) ..................... 11
3-7. POWER Board (SA-WSF200/WSF500) ........................ 11
4. DIAGRAMS
4-1. Block Diagram
- DSP Section (SA-WSF200/WSF500) - ........................ 12
4-2. Block Diagram
- AMP Section (SA-WSF200/WSF500) - ....................... 13
4-3. Block Diagram - POWER SUPPLY Section
(SA-WSF200/WSF500) - ............................................... 14
4-4. Printed Wiring Board - AMP-DSP Board
(Component Side) (SA-WSF200/WSF500) - ................. 16
4-5. Printed Wiring Board - AMP-DSP Board
(Conductor Side) (SA-WSF200/WSF500) - ................... 17
4-6. Schematic Diagram
- AMP-DSP Board (1/3) (SA-WSF200/WSF500) - ........ 18
4-7. Schematic Diagram
- AMP-DSP Board (2/3) (SA-WSF200/WSF500) - ........ 19
4-8. Schematic Diagram
- AMP-DSP Board (3/3) (SA-WSF200/WSF500) - ........ 20
4-9. Printed Wiring Boards
- SPEAKER Section (SA-WSF200/WSF500) - ............. 21
4-10. Schematic Diagram
- SPEAKER Section (SA-WSF200/WSF500) - ............. 21
4-11. Printed Wiring Board
- POWER Board (SA-WSF200/WSF500) - ................... 22
4-12. Schematic Diagram
- POWER Board (SA-WSF200/WSF500) - ................... 23
4-13. Printed Wiring Board
- REG Board (SA-WSF200/WSF500) - ......................... 24
4-14. Schematic Diagram
- REG Boards (SA-WSF200/WSF500) - ........................ 24
5. EXPLODED VIEWS
5-1. Cabinet Section (SA-WSF200/WSF500) ....................... 36
5-2. AMP Complete Assy (SA-WSF200/WSF500) ............... 37
5-3. AMP Board Section (SA-WSF200/WSF500)................. 38
5-4. POWER board Section (SA-WSF200/WSF500) ............ 39
5-5. SS-CTF500/TSF200/TSF500 ......................................... 40
8-6. Speaker Stand (for SS-TSF500) ..................................... 41
6. ELECTRICAL PARTS LIST .............................. 42
TABLE OF CONTENTS
NOTES ON CHIP COMPONENT REPLACEMENT
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
SAFETY-RELATED COMPONET WARNING!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR
LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES
PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONC-
TIONNEMENT. NE REMPLACER CES COMPOSANTS QUE
PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DON-
NÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS
PUBLIÉS PAR SONY.
Accessories are given in the last of the electrical parts list.
Subwoofer (SA-WSF500)
Power requirements:
Canadian and Mexican models:
120 V AC, 60 Hz
Taiwan model: 120 V AC, 50/60 Hz
Latin American model: 110 V – 240 V AC, 50/60 Hz
Korean model: 220 V AC, 60 Hz
Thai model: 220 V, 50/60 Hz
Other models: 220 V – 240 V AC, 50/60 Hz
Power consumption On: 135 W
Standby: 0.3 W (at the
Power Saving mode)
Speaker system Subwoofer Bass reflex
Speaker unit 160 mm cone type
Rated impedance 3 ohms
Dimensions (approx.) 205 mm × 460 mm × 475
mm (w/h/d)
Mass (approx.) 13 kg
Design and specifications are subject to change
without notice.
A
mplifier Section
Power output (rated)
RMS output power (reference)
108 W + 108 W (at 3 ohms,
1 kHz, 1% THD)
FL/FR/C*: 141 W
(per channel at 3 ohms,
1 kHz, 10% THD)
Subwoofer*: 141 W (at 3
ohms, 80 Hz, 10% THD)
* Depending on the decoding mode settings and the
source, there may be no sound output.
Ver. 1.1
