HCD-F200/F500
14
3-7. MAIN
BLOCK
Note:
Please spread a seat under a set not to injure front panel assy
.
screw
(BVTP3
×
6)
screw
(BVTP3
×
6)
two
screws
(BVTP3
×
8)
screw
(BVTP3
×
8)
wire (flat type) (17 core)
(CN851)
RB
three
claws
RE
main
block
ground plate (bridge)
two
screws
(BVTP3
×
6)
bracket shield-F (HCD)
– rear view –
– rear view –
tape (rong BU)
connector
(CN502)
RT
RB
two
claws
RB
two
claws
67
69
