58
US
– “PLIIx Movie” and “PLIIx Music” are
available only when the speaker pattern
is set to a setting with surround back
speaker(s).
– “PLIIz Movie” and “PLIIz Music” are
available only when the speaker pattern
is set to a setting with front high
speakers.
• The sound fields for music and movie do
not work in the following cases.
– DTS-HD Master Audio, DTS-HD High
Resolution Audio or Dolby TrueHD
with sampling frequency of more than
48 kHz are being received.
– “2ch Analog Direct” is selected.
• “PLII Movie”, “PLII Music”, “PLIIx
Movie”, “PLIIx Music”, “PLIIz Movie”,
“PLIIz Music”, “Neo:6 Cinema” and
“Neo:6 Music” do not work when the
speaker pattern is set to 2/0 or 2/0.1.
• When one of the sound fields for music is
selected, no sound is output from the
subwoofer if all the speakers are set to
“Large” in the Speaker Settings menu.
However, the sound will be output from
the subwoofer if
– the digital input signal contains LFE
signals.
– the front or surround speakers are set to
“Small”.
– “Multi Stereo”, “PLII Movie”, “PLII
Music”, “PLIIx Movie”, “PLIIx
Music”, “PLIIz Movie”, “PLIIz
Music”, “HD-D.C.S.” or “Portable
Audio” is selected.
Adjusting the equalizer
You can use the following parameters to
adjust the tonal quality (bass/treble level)
of front, center, surround/surround back
and front high speakers.
1 Select “Sound Effects” from the
home menu, then press .
2 Select “Equalizer”, then press .
3 Select “Front”, “Center”,
“SUR/SB”, or “Front High”, then
press .
4 Select “Bass” or “Treble”, then
adjust the gain.
• This function does not work when “2ch Analog
Direct” is being used.
• Frequencies for Bass and Treble are fixed.
• Depending on the audio format, the receiver
may play back signals at a lower sampling
frequency than the original sampling frequency
of the input signals.
Notes
Level
(dB)
Bass Treble
Frequency (Hz)
