491
Deleting Tally Copy
1
In the Engineering Setup >Router/Tally >Tally Copy
menu (7365), select the tally copy.
2
Press [Delete].
Parallel Tally Settings
You can configure the parallel port on which to output tally
information for each source and destination. For each tally
output port, specify the source address or destination level
and address, and the tally type.
Configuring/Modifying Parallel Tally
1
In the <Device> group of the Engineering Setup
>Router/Tally >Parallel Tally menu (7366), select one
of the following.
DCU1: Set the SIU1 (DCU function) parallel tally.
DCU2: Set the SIU2 (DCU function) parallel tally.
2
Select the slot number and port number.
On the MKS-X2700, select 2 for the slot and a value in
the range 1 to 36 for the port.
3
Press [Set].
The Set menu (7366.1) appears.
4
In the <Source/Destination> group, select the tally
type.
Src: Return a tally to all sources that are output to the
destination.
Dest: Return a tally to destinations outputting sources
that return a tally using source tally.
5
Set the address and level.
The level setting is only required when [Dest] is
selected in step 4.
6
Set the tally type.
No. Parameter Adjustment
1 Slot No Parallel tally slot number
2 Port No Parallel tally port number
Note
No. Parameter Adjustment
1 Address Source/destination address
2 Level Destination level
To Next Page
