Legacy U.S.A. (E)
4-16
HEATER OPERATION
J Defrosting or defogging the windshield
OM-H2510
OFF position
OM-H2509
To direct warm air to the windshield and front door windows:
1. Set the air inlet selection button to the “OFF” position.
2. Push the “
” button in.
3. Set the temperature control lever all the way to the right in the red
area.
4. Set the fan speed control dial to high.
B Adjustable side defroster grille (for driver’s side – if equipped)
HB0194HB0193
Normal position
Side defroster
grille
Fin
Windshield defrost
assist position
The driver’s side defroster grille is adjustable. The normal positions as
shown in the diagram directs warm air to the side glass. When more
rapid defrosting of the windshield is desired, the air flow can be
To Next Page
