Sungrow SG2500HV-30 User Manual

15
NNoo.. NNaammee
DDeessccrriippttiioonn
A
AC maintenance
switch
Disconnect the switch before maintaining AC cabinet
components.
B
DC load break
switch
Control the connection/disconnection on the DC side
of the inverter
C Fuse
—
D
DC connection
area
The upper part of the copper bar is for positive cable
connection area while the lower part is for negative
cable connection
E
DC maintenance
switch
Disconnect the switch before maintaining DC cabinet
components.
AACC CCaabbiinneett
NNoo.. NNaammee
DDeessccrriippttiioonn
A
Heat exchanger
—
B
AC circuit
breaker
Control the connection/disconnection on the DC side
of the inverter
C RS485 terminals
—
3.2.3 Operations on the DC and AC Side
Los interruptores de carga de CC y los disyuntores de CA se proporcionan en el inversor.
System Manual 3 Product Description

Sungrow SG2500HV-30 Specifications
