29
5.4 Removing the Sealing Tapes
Before delivery, the air inlet of the inverter and the heat exchanger are all pasted with
sealing tapes, shown as A and B respectively. Removing these sealing tapes before the
inverter is put into operation.
5.5 Installing the Ventilation Cover(optional)
The operations described in this section are only applicable to the models that
ordered the ventilation cover.
IInnssttaallllaattiioonn PPaarrttss PPrreeppaarraattiioonn
NNoo.. NNaammee
DDeessccrriippttiioonn
1 Plate 1
1Pcs,installed on the left side of the inverter
2 Plate 2
1Pcs,installed on the right side of the inverter
3
C-type plate 1Pcs,installed on the right side of the inverter
4 M6x16 screw 14
System Manual 5 Mechanical Installation
