POWER UNIT 7-3
[ Remote control model ]
• Remove bolt 1 , throttle drum 2, throttle cam link rod3 and
remote control throttle link rod 4 .
• Remove bolt 5 , clutch control lever 6 , throttle control lever
7 and clutch lever link rod 8 .
Remove fuel pump 1 (see page 5-14)
Remove bolt 2 and fuel filter bracket 3 .
Remove inlet case 4 and three carburetor assembly 5 . (see
page 5-4)
Disconnect choke solenoid lead wire. (Remote control models)

Suzuki DF 25 Specifications

General

Ignition System	Digital CDI
Engine Mounting	Shear Mount
Maximum Output	25 hp
Starting System	Electric
Steering	Tiller
Trim Method	Manual
Shaft Length	381 mm / 508 mm
Exhaust	Through propeller hub
