Suzuki DF 25 Service Manual

ENGINE CONTROL 3-19
OIL PRESSURE SWITCH
REMOVAL
Loosen screw and disconnect blue/yellow lead wire from switch.
Remove oil pressure switch from crankcase.
INSTALLATION
Installation is reverse order of removal with special attention to
the following steps.
• Before installing oil pressure switch , wrap screw threads with
sealing tape then tighten switch to specified torque.
NOTE:
Cut off any excess sealing tape from switch threads before in-
stallation .
!!
!!
! Oil pressure switch : 13 N
.
m (1.3 kg-m, 9.5 lb.-ft.)
• Start engine and check oil pressure switch for oil leakage.
Reseal switch if oil leakage is found.
1. Sealing tape
1

Suzuki DF 25 Specifications

General

Ignition System	Digital CDI
Engine Mounting	Shear Mount
Maximum Output	25 hp
Starting System	Electric
Steering	Tiller
Trim Method	Manual
Shaft Length	381 mm / 508 mm
Exhaust	Through propeller hub
