8-10 MID UNIT
Remove bolts 5 and upper mount cover 6.
Remove upper mount assembly 7.
Remove lower mount assembly 8.
Remove four bolts 9 and engine holder 0.
Remove bolts A and oil strainer B.
Note the position of O-ring and remove it.
Remove three bolts C and oil pump assembly D.
