FI SYSTEM DIAGNOSIS 4-13
FI SYSTEM WIRING DIAGRAM
IG2 IG1
O/G
B/Y
W/Bl
B
B/Bl
Br
Gr/W
Gr/B
B/R R/B
Dg
R
P/W
B/Br
W/B
W/G
Y P
W
B/W
W/R
G/B
Br/B
B/G
B/W B/W
Y/B
Br/W
O/R
MODE SELECTION SWITCH
SPEEDOMETER
INTAKE AIR
PRESSURE
SENSOR
PAIR SOLENOID
CONTROL VALVE
SIDE- STAND SWITCH
GEAR POSITION SWITCH
CLUTCH SWITCH
FP
DON
AT
+B
CLT
IG1
THW
THA
VCC
TPS
E2
STPS
HO2 (OXH)
HO2 (OX)
GP
N+
E1
TS
PM
TAC O
E01 E02
TECH
SOL
Fl #1 Fl #2
MO+
MO–
IG2
IGNITION COIL
30 A
10 A 10 A 10 A
NEUTRAL
LAMP
SIDE-STAND RELAY
ENGINE STOP
SWITCH
FUEL PUMP RELAY
TIP OVER SENSOR
MAIN
SWITCH
BATTERY
ECM
FUEL PUMP
STARTER
BUTTON
STARTER
RELAY
STPS
IATS
STVA
TPS
ECTS
CKPS
Fl
8
HO2
