2-28 PERIODIC MAINTENANCE
CHASSIS BOLT AND NUT
Check that all chassis bolts and nuts are tightened to their specified torque. (Refer to page 2-29 for the loca-
tions of the following nuts and bolts on the motorcycle.)
Tighten initially at 1 000 km (600 miles, 2 month) and
every 6 000 km (4 000 miles, 12 months) thereafter.
ITEM N·m kgf-m lb-ft

1 Steering stem head nut 90 9.0 65.0

2 Steering stem lock-nut 80 8.0 58.0

3 Front fork upper clamp bolt 23 2.3 16.5

4 Front fork lower clamp bolt 23 2.3 16.5

5 Front axle 65 6.5 47.0

6 Front axle pinch bolt 23 2.3 16.5

7 Handlebar clamp bolt 23 2.3 16.5

8 Front brake master cylinder mounting bolt 10 1.0 7.0

9 Front brake caliper mounting bolt 39 3.9 28.0

0 Brake hose union bolt 23 2.3 16.5

A Air bleeder valve (Front) 7.5 0.75 5.5

B Air bleeder valve (Rear) 6 0.6 4.3

C Brake disc bolt (Front & Rear) 23 2.3 16.5

D Rear brake caliper mounting bolt 22 2.2 16.0

E Rear brake master cylinder mounting bolt 10 1.0 7.0

F Rear brake master cylinder rod lock-nut 18 1.8 13.0

G Front footrest bracket mounting bolt 25 2.5 18.0

H Swingarm pivot nut 100 10.0 72.5

I Swingarm pivot lock-nut 90 9.0 65.0

J Rear shock absorber mounting nut
(Upper & Lower)
50 5.0 36.0

K Cusion lever nut 78 7.8 56.5

L Cusion rod nut 78 7.8 56.5

M Rear axle nut 100 10.0 72.5

N Seat rail mounting bolt 50 5.0 36.0
