9-42 SERVICING INFORMATION
CHASSIS
ITEM
N·m kgf-m lb-ft
Steering stem head nut 90 9.0 65.0
Steering stem lock-nut 80 8.0 58.0
Front fork upper clamp bolt 23 2.3 16.5
Front fork lower clamp bolt 23 2.3 16.5
Front fork cap bolt 23 2.3 16.5
Front fork cylinder bolt 20 2.0 14.5
Front axle 65 6.5 47.0
Front axle pinch bolt 23 2.3 16.5
Handlebar clamp bolt 23 2.3 16.5
Front brake master cylinder mounting bolt 10 1.0 7.0
Front brake caliper mounting bolt 39 3.9 28.0
Brake hose union bolt 23 2.3 16.5
Front caliper air bleeder valve 7.5 0.75 5.5
Rear caliper air bleeder valve 6 0.6 4.3
Brake disc bolt (Front and Rear) 23 2.3 16.5
Rear brake caliper mounting bolt 22 2.2 16.0
Rear brake caliper sliding pin 27 2.7 19.5
Rear brake pad mounting pin 17 1.7 12.5
Rear brake pad mounting pin plug 2.5 0.25 1.8
Rear brake master cylinder mounting bolt 10 1.0 7.0
Rear brake master cylinder rod lock-nut 18 1.8 13.0
Front footrest bracket mounting bolt 25 2.5 18.0
Swingarm pivot shaft 15 1.5 11.0
Swingarm pivot nut 100 10.0 72.5
Swingarm pivot lock-nut 90 9.0 65.0
Rear shock absorber mounting nut (Upper & Lower) 50 5.0 36.0
Cushion lever nut 78 7.8 56.5
Cushion rod nut 78 7.8 56.5
Rear axle nut 100 10.0 72.5
Rear sprocket nut 60 6.0 43.5
Seat rail mounting bolt 50 5.0 36.0
Side stand bracket mounting bolt 100 10.0 72.5
Side stand bolt 50 5.0 36.0
Side stand nut 40 4.0 29.0
