COOLING AND LUBRICATION SYSTEM 6-15
• Remove the water pump

6 from the clutch cover.
• Remove the screws and separate the water pump.
• Remove the O-rings

7.
• Remove the E-ring from the impeller shaft.
• Remove the impeller from the other side.
• Remove the mechanical seal ring

5 and rubber seal

6 from
the impeller.
