CHASSIS 7-29
• Remove the steering stem upper bracket by removing the
steering stem head nut.
• Remove the steering stem lock-nut with the special tools.
$ 09940-14911: Steering stem nut wrench
09940-14960: Steering stem nut wrench socket
• Remove the washer

4.
• Remove the steering stem nut with the special tools.
$ 09940-14911: Steering stem nut wrench
09940-14960: Steering stem nut wrench
NOTE:
When loosing the steering stem nut, hold the steering stem
lower bracket to prevent it from falling.
• Remove the steering stem lower bracket.
• Remove the dust seal

5 and bearing inner race

6.
