ELECTRICAL SYSTEM 8-13
Step3
1) Measure the starter relay voltage at the starter relay connectors (between B/Y and Y/G) when the starter
button is pushed.
Is a voltage OK?
Step4
1) Inspect the starter relay. (!8-19)
Is the starter relay OK?
Step5
The starter motor runs when the transmission is neutral with the side-stand up or down, but does not run
when the transmission is in any position other than neutral with the side-stand down.
1) Inspect the side-stand switch. (!8-20)
Is the side-stand switch OK?
Engine does not turn though the starter motor runs.
Faulty starter clutch. (!3-79)
YES Go to Step4.
NO
• Faulty gear position switch.
• Faulty starter button.
• Faulty engine stop switch.
• Faulty turn signal/side-stand relay.
• Faulty ignition switch.
• Faulty clutch switch.
• Faulty side-stand switch.
• Improper connector contact.
• Open circuit in wire harness.
YES Poor starter relay connection.
NO Faulty starter relay.
YES • Open circuit in wire harness.
• Poor contact of connector.
NO • Faulty side-stand switch.
