ELECTRICAL SYSTEM 8-31
ODOMETER
The odometer indicates “------” when the odometer is faulty.
Replace the combination meter unit with a new one.
TRIP METER
The trip meter indicates “----.-” when the trip meter is faulty.
In case the odometer works normaly, perform the trip meter
reset. If the trip meter isn’t restored after above reset, replace
the combination meter unit with a new one.
TRIP METER RESET PROCEDURE
1. Turn the ignition “ON”.
2. Select the trip meter by pushing the SEL switch

A.
3. Push the ADJ switch

B for 2 seconds.
PartShark.com
877-999-5686

Suzuki DL650K5 Specifications

General

Displacement	645 cc
Bore x Stroke	81.0 mm x 62.6 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Lubrication	Wet sump
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Ground Clearance	170 mm
Seat Height	835 mm
Engine Type	4-stroke, liquid-cooled, DOHC
Ignition	Digital/Transistorized
Front Tire Size	110/80R19
Rear Tire Size	150/70R17
Overall Width	840mm
Overall Height	1405mm
Fuel Capacity	20.0L
Torque	62 Nm
