FI SENSORS+ SECONDARY THROTTLE VALVE ACTUATOR
THROTTLE BODY
ITEM SPECIFICATION NOTE
CKP sensor resistance 130 – 240 Ω W – G
CKP sensor peak voltage 3.7 V (When cranking) and more
IAP sensor input voltage 4.5 – 5.5 V
IAP sensor output voltage
Approx. 2.7 V at idle speed

+ G/B –

-
B/Br
TP sensor input voltage 4.5 – 5.5 V
TP sensor resistance Closed Approx. 1.12 kΩ
Opened Approx. 4.26 kΩ
TP sensor output voltage Closed Approx. 1.12 V

+ P/W –

-
B/Br
Opened Approx. 4.26 V
ECT sensor input voltage 4.5 – 5.5 V
ECT sensor resistance Approx. 2.45 kΩ at 20 °C (68 °F)
IAT sensor input voltage 4.5 – 5.5 V
IAT sensor resistance Approx. 2.45 kΩ at 20 °C (68 °F)
TO sensor resistance 19.1 – 19.7 kΩ
TO sensor voltage Normal 0.4 – 1.4 V

+ Br/W –

-
B/Br
Leaning 65 ° 3.7 – 4.4 V
GP switch voltage 1.0 V and more (From 1st to Top)
Injector voltage Battery voltage
STP sensor input voltage 4.5 – 5.5 V
STP sensor resistance Closed Approx. 0.58 kΩ
Y – B
Opened Approx. 4.38 kΩ
STP sensor output voltage Closed Approx. 0.58 V

+ Y –

-
B/Br
Opened Approx. 4.40 V
STV actuator resistance 7 – 14 Ω
PAIR solenoid valve resistance 20 – 24 kΩ at 20 °C (68 °F)
ITEM SPECIFICATION
I.D. No. 27 G0 (Others), 27 G1 (For E-33)
Bore size 39 mm
Fast idle r/min. 1 800 – 2 400 r/min at 25 °C (77 °F)
Idle r/min. 1 300 ± 100 r/min/Warmed engine
Throttle cable play 2.0 – 4.0 mm
(0.08 – 0.16 in)
DL650K6 ('06 MODEL) 12- 9
