FI SENSORS + STVA + ISC VALVE
THROTTLE BODY
ITEM SPECIFICATION NOTE
CKP sensor resistance 130 – 240 Ω W – G
CKP sensor peak voltage 3.7 V (When cranking) and more
IAP sensor input voltage (F & R) 4.5 – 5.5 V
IAP sensor output voltage (F & R) * Approx. 1.6 V at idle speed
TP sensor input voltage 4.5 – 5.5 V
TP sensor output voltage Closed * Approx. 1.1 V
+ P/W –
- B/Br
Opened * Approx. 4.3 V
ECT sensor input voltage 4.5 – 5.5 V
ECT sensor resistance Approx. 2.45 kΩ at 20 °C (68 °F)
IAT sensor input voltage 4.5 – 5.5 V
IAT sensor resistance Approx. 2.45 kΩ at 20 °C (68 °F)
TO sensor resistance * 16.5 – 22.3 kΩ
TO sensor voltage Normal 0.4 – 1.4 V
+ Br/W –
- B/Br
Leaning 65° 3.7 – 4.4 V
GP switch voltage 1.0 V and more (From 1st to Top)
Injector voltage Battery voltage
STP sensor input voltage 4.5 – 5.5 V
STP sensor output voltage Closed * Approx. 0.6 V
+ Y –
- B/Br
Opened * Approx. 4.5 V
STV actuator resistance * Approx. 7 Ω
Heated oxygen sensor output volt-
age
0.4 V and less at idle speed
E-02, 19, 24, 41
0.6 V and more at 5 000 r/min
Heated oxygen sensor resistance * 11 – 15 Ω at 23 °C (73.4 °F) E-02, 19, 24, 41
PAIR solenoid valve resistance 20 – 24 kΩ at 20 °C (68 °F)
ISC valve resistance * Approx. 30 ± 1.2 Ω at 20 °C (68 °F)
ITEM SPECIFICATION
I.D. No. * 27 G2 (Others), 27 G3 (For E-33)
Bore size 39 mm
Fast idle r/min. * 1 800 – 2 200 r/min at 25 °C (77 °F)
Idle r/min. 1 300 ± 100 r/min/Warmed engine
Throttle cable play 2.0 – 4.0 mm
(0.08 – 0.16 in)
13-148 DL650K7/AK7 (’07-MODEL)
