546 TMAA04-04 Crossband Linking Cable TM8100/TM8200 Service Manual

Ref. IPN Description

27.5 PCB Information

27.5.1 TMAA04-04 Parts List (PCB IPN 220-02127-01)

C2 018-16100-00 Cap 0603 100n 16v x7r + - 10%

C10 018-16100-00 Cap 0603 100n 16v x7r + - 10%

J1 240-00031-00 Plg 15w Drng UL-CSA Pnl Mtg

R1 038-13560-10 RES 0603 560R 1% 1/10W

R6 038-13560-10 RES 0603 560R 1% 1/10W

205-00110-50 CBL 8wy Oval Std Telecom

219-03005-00 CBL TMA X-Band

220-02127-01 PCB MFX Programming cable

240-00031-00 Plg 15w Drng UL-CSA Pnl Mtg

240-06010-18 Conn 15w Hood/Cvr Drng MDJ15

402-00030-0X MANL f/instr TMAA04-04 XB
