566 TMAA10-04 Remote PTT Kit and TMAA10-05 Hands-Free Kit TM8100/TM8200 Service Manual

Ref. IPN Description

32.7 PCB Information

32.7.1 TMAA10-04/TMAA10-05 Parts List (PCB IPN 220-01711-01)

C2 015-26330-08 Cap Cer 0805 330n 5% 10v X7r

C3 018-15100-00 Cap 0603 10n 50v X7r +-10%

C4 015-26330-08 Cap Cer 0805 330n 5% 10v X7r

C6 015-26100-08 Cap Cer 0805 100n 10% X7r 50v

C7 015-26100-08 Cap Cer 0805 100n 10% X7r 50v

Q1 000-10084-71 Xstr BC847BW NPN SOT323

Q2 000-10085-71 Xstr SMD BC857BW PNP SOT323

Q3 000-10084-71 Xstr BC847BW NPN SOT323

Q4 000-10084-71 Xstr BC847BW NPN SOT323

R1 038-14220-00 Res 0603 2k2 1/16w +-5%

R3 038-14390-10 Res 0603 3k9 1%

R4 038-15470-10 Res 0603 47k 1/16w+-1%

R6 038-15330-10 Res 0603 33k 1%

R13 038-15100-10 Res 0603 10k 1/16w +-1%

R16 038-15470-10 Res 0603 47k 1/16w+-1%

R17 038-15150-00 Res 0603 15k 1/16w +-5%

R18 038-15100-10 Res 0603 10k 1/16w +-1%

R19 038-15100-10 Res 0603 10k 1/16w +-1%

219-00305-00 cable

220-01711-01 Pcb HFree

240-06010-18 Conn 15w Hood/Cvr Drng MDJ15

252-00010-72 Mic Electret Unidir 2.5mm Plg

402-00006-01 F/Inst TMAA10-04/TMAA10-05 Eng

TMAA10-04 Remote PTT only

236-00001-00 Sw Ptt W/Cbl & Strap
