TC-Helicon Voicelive 2 Basic Manual

17
First Impressions
Using The Effect On/Off Switches
The Effect On/Off footswitches give you the option
to modify the sound without changing to another
preset. You can do so by tapping any of the 6
effects footswitches which include µMOD (pronounced
“micromod”), DELAY, REVERB, HARMONY, DOUBLE
AND FX.
Tapping an effect that’s off will add it to the effects
mix and vice versa. All effects have default settings so
you can merely press their associated footswitches to
add them to your preset without editing. When you
advance to the next preset, your on/off settings will be
lost unless stored.
The SHORTCUT Footswitch
This footswitch extends the capabilities of the current
preset. Depending on the preset, it could allow you to
engage Harmony Hold, set the tempo for the Delay or
turn on the Choir effect. The shortcut assignment for
the current preset is clearly shown in the HOME screen.
Some shortcuts require holding the footswitch (e.g.
Harmony Hold) and some require tapping it (e.g. Delay
tempo). Every preset has a shortcut, so be sure to
familiarize yourself with them all while exploring the
product.

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
