selected digital input on presets where NATURALPLAY
is set to AUX INPUT.
Digital Output Notes:
USB audio output will not function when either of the
SPDIF: options is chosen for the DIGITAL IN parameter.
SPDIF digital output is always available regardless of
DIGITAL IN or OUT settings.
USB Audio And ASIO Applications
PC-based ASIO apps such as Cubase may require you
to install a WDM to ASIO “wrapper” such as ASIO4ALL
which is available at www.asio4all.com in order for
VoiceLive 2 to be recognized as an audio device.
Selecting The Audio Device
In the Mac and Vista operating systems, you can select
VoiceLive 2’s audio device in your workstation program
by name. In some Windows XP DAW apps, however,
the name of the audio device may be “USB Audio
Device”.
USB And MIDI Control
To use VoiceLive 2’s MIDI IN jack for harmony, preset
change or realtime control while USB is connected,
enter the I/O tab in the SETUP menu and set USB
CONTROL to OFF. USB audio will function normally
but MIDI will only be accepted by VoiceLive 2 through
its MIDI IN port.
To re-enable VoiceSupport’s features and reception of
MIDI from your DAW, turn USB CONTROL to ON.
Connecting VoiceLive 2 To A Computer
33

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
