TC-Helicon Voicelive 2 Basic Manual

“Borrowing” From Another Player
If you play with a guitarist or MIDI keyboard player, you
can use their playing to guide the harmony voices in your
VoiceLive 2.
Your guitarist can connect to the GUITAR IN and THRU
then to their pedalboard or amp. Their guitar sound will
remain the same and you can turn the harmonies on
and off when you need them. The only limitation is
the length of cable because high impedance signals lose
signal over long cable runs. If this is an issue, you could
use a preamp out or effects loop output from the amp.
Alternatively, you can run a MIDI cable from your
keyboardist’s controller to your VoiceLive 2. This has no
effect on the keyboard sound and cable runs are not a
problem.
With either solution, you can co-ordinate with the
player to make sure they are playing complete chords
where you plan to use harmony.
VoiceLive 2 for the Lead Singer
28

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
