Tektronix DPO3000 Series User Manual

Display Waveform Data
2. Turn multipurpose knob a to ad just the v ertical
position of the selected bus.
Labeling B us Signals. To label a bus, do the following steps:
1. Push the appropriate front-panel bus button.
2. Push Label.
(See page 79, Labeling Channels and Buses.)
Bus (B1)
Parallel
Define
Inputs
Thresholds
(B1) Label
Parallel
Bus Display Event Table
152 DPO3000 Series Oscilloscopes User Ma nual
