Pattern and state trigger sensitivity
DC coupled, typical, ≥4 GHz
models
15% x FS from DC to 1 GHz, not violating the minimum timing requirements for each type (for
vertical settings from 10 mV/div to 1 V/div at input connector)
Logic and state trigger sensitivity
DC coupled, typical, <4 GHz
models
1.0 division from DC to 1 GHz (for vertical settings from 10 mV/div to 1 V/div at input connector)
Logic and state trigger minimum
timing requirements, typical,
<4 GHz models
Minimum duration of logic state: 100 ps (10 GB/s). The minimum duration of the logic pattern
includes delay mismatch between channels.
Minimum pulse width Rearm time
Logic type 100 ps (10 GB/s) 100 ps
State type 500 ps 500 ps
Time qualified logic type 300 ps 500 ps
Video-type trigger formats and
field rates, <4 GHz models
Triggers from negative sync composite video, field 1 or field 2 for interlaced systems, any field,
specific line, or any line for interlaced or non-interlaced systems. Supported systems include NTSC,
PAL, SECAM, and HDTV 1080/24sF, 1080p/25, 1080i/50, 1080i/60, 1080p/24, 720p/60, 480p/60.
Timeout trigger minimum timing
requirements
Timeout event occurs after the signal has stayed in some state the minimum amount of time. Setup
and hold times are how long before and after the timeout event the logic level must remain valid in
order to generate a trigger.
≥4 GHz models
Minimum
pulse width
Minimum
rearm time
Setup time Hold time
Timeout type N.A. 300 ps + pulse
width
N.A. N.A.
Logic qualified timeout type N.A. 300 ps + pulse
width
50 ps 50 ps
<4 GHz models
Minimum
pulse width
Minimum
rearm time
Setup time Hold time
Timeout type 300 ps 500 ps + pulse
width
N.A. N.A.
Logic qualified timeout type 300 ps 500 ps + pulse
width
200 ps 200 ps
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Trigger specifications (cont.)
62 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
