Tektronix DPO70000C/DX Series User Manual

Compliance info
rmation
Compliance in
formation
This section lists the EMC (electromagnetic compliance), safety, and environmental standards with which the instrument
complies.
EMC compliance
EC Declarati
on of Conformity – EMC
Meets intent of Directive 2004/108/EC for E lectromagnetic Compatibility. Compliance was demonstrated to the following
specifications as listed in the Official Journal of the European Communities:
EN 61326-1:2006, EN 61326-2-1:2006. EMC requirements for electrical equipment for measurement, control, and
laborator
yuse.
123
CISPR 11:2
003. Radiated and conducted emissions, Group 1, Class A
IEC 61000
-4-2:2001. Electrostatic discharge immunity
IEC 61000
-4-3:2002. RF electromagnetic fi eld immunity
4
IEC 61000
-4-4:2004. Electrical fast transient/burst immunity
IEC 6100
0-4-5:2001. Power line surge immunity
IEC 6100
0-4-6:2003. Conducted RF immunity
4
IEC 6100
0-4-11:2004. Voltage dips and interruptions immunity
EN 61000-3-2:2006. AC power line harmonic emissions
EN 6100
0-3-3:1995.
Voltage changes, fluctuations, and flicker
European contact.
Tektronix UK, Ltd.
Western Peninsula
Western Road
Bracknell, RG12 1RF
United Kingdom
1
This
product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic interference.
2
Emissions which exceed the levels required by this standard may occur when this equipment is connected to a test object.
3
If interconnect cables are used, they must be low–EMI shielded cables such as the following Tektronix part numbers or
theirequivalents: 012-0991-01, 012-0991-02 or 012-0991-03 GPIB Cable; 012-1213-00 (or CA part number 0294-9) RS-232
Cabl
e;012-1214–00 Centronics Cable; or LCOM part number CTL3VGAMM-5 VGA Cable. Use an 012-0482-00 cable for the Ref
Out connector.
4
The p
erformance criterion for when the oscilloscope is subjected to the continuously present electromagnetic phenomenon:
MSO70000C/DX, DPO70000C/DX, and DPO7000: 10 mV/division to 1 V/division: ≤0.4 division waveform displacement or
≤0.8 division increase in peak–to–peak noise. MSO5000 and DPO5000: ≤4.0 division waveform displacement or ≤8.0 divis ion
increase in peak–to–peak noise.
5
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series User Manual ix
