Command Description
TRIGger:A:RUNT:WIDth on page 239 Sets or returns the width for a runt trigger.
TRIGger:A:TYPe on page 240 Sets or queries the type of instrument trigger.
TRIGger:A:UPPerthreshold:CH<x> on
page 241
Sets the upper threshold for channel <x>, where
x is the channel number. Each channel can have
an independent level. Used only for runt trigger
type.
TRIGger:FREQuency? on page 242 Returns the edge or pulse width trigger
frequency.
TRIGger:STATE? on page 242 Returns the current state of the triggering
system.
Vertical command group
Vertical commands control the attributes of the channels. The SELect:<wfm>
command also displays a specified waveform or removes it from the display.
Table 23: Vertical commands
Command Description
CH<x>? on page 60 Returns vertical parameters for the specified
channel.
CH<x>:BANdwidth on page 60 Sets or queries the bandwidth setting of the
specified instrument channel.
CH<x>:COUPling on page 61 Sets or queries the input coupling setting of the
specified instrument channel.
CH<x>:DESKew on page 62 Sets or queries the deskew time for the specified
channel
CH<x>:INVert on page 63 Sets or returns the invert function for the
specified channel.
CH<x>:OFFSet on page 63 Sets or queries the channel offset.
CH<x>:POSition on page 64 Sets or queries the vertical position of the
specified instrument channel.
CH<x>:PRObe on page 65? Returns the gain, resistance, units, and ID of the
probe that is attached to the specified channel.
CH<x>:PRObe:AUTOZero on page 66 Sets the TekVPI probe attached to the specified
channel input to autozero.
CH<x>:PRObe:DEGAUss on page 66 Starts a degauss/autozero cycle on a TekVPI
current probe attached to the specified channel
input.
CH<x>:PRObe:DEGAUss:STATE? on
page 67
Returns the state of the probe degauss.
CH<x>:PRObe:FORCEDRange on page 68 Sets or queries the range on a TekVPI probe
attached to the specified channel.
Command groups
28 TBS2000 Series Programmer
