A.1.4 LAN switch connector
Devices featuring this interface are equipped with four RJ45 connectors.
RJ45 LAN RJ45 PIN FE Signals GE Signals
1
2
3
4
5
6
7
8
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
A.1.5 WWAN/RF connectors
Devices featuring this interface are equipped with two SMA female connectors.
SMA Female PIN ANT
Internal
External
RF in/out
GND
A.1.6 Configuration connector
RJ45 CONFIGURATION PIN CONF
1
2
3
4
5
6
7
8
--
TxD (input)
GND
--
--
GND
RxD (output)
--
