Teldat Regesta Smart PRO User Manual

A.2.10.1 AC model
NOMINAL 110-240 V AC.
ABSOLUTE MAXIMUM 85-264 V AC.
FREQUENCY 50-60 Hz
MAXIMUM POWER 10 W
CONNECTOR
2-pole 5.08 mm pitch terminal block .
A.2.10.2 DC model
NOMINAL 12-72 V DC
ABSOLUTE MAXIMUM
9 - 80 V DC
MAXIMUM POWER 10 W
CONNECTOR
2-pole 5.08 mm pitch terminal block.
A.2.10.3 MR model
NOMINAL 110-240 V AC
48-72 V DC
ABSOLUTE MAXIMUM 85-264 V AC
40 - 85 V DC
FREQUENCY 50-60 Hz (AC)
MAXIMUM POWER 10 W
CONNECTOR
2-pole 5.08 mm pitch terminal block.
A.2.11 Dimensions and weight
TYPE Plastic ruggedized casing with optional DIN rail mount.
LENGTH x WIDTH x HEIGHT 140 x 80 x 190 mm.
WEIGHT 1 Kg.
A.2.12 Environmental specifications
TEMPERATURE RANGE OPERATION: -20 ºC to +70 ºC
STORAGE: -25º to +70 ºC
RELATIVE HUMIDITY 5 % to 93 %
Teldat S.A.
Technical Information
Regesta Smart PRO 41
