Tenda F9 User Manual

Status
Description
The WiFi function is enabled.
The WiFi function is disabled.
6.2 WiFi Name and Password
In this part, you can change the WiFi name, security mode, and WiFi password.
Parameters
Parameters
Description
WiFi Name
It specifies the wireless network name. When the router is connected to the internet
successfully, wireless clients, such as smart phones, can connect to this name for internet
access.
Hide WiFi
When this option is selected, the wireless clients cannot search the WiFi name of the router,
and you need to enter it on your device manually.
Security Mode
It specifies the security mode of the wireless network.
 None: A wireless client can connect to the wireless network without a password.
 WPA-PSK: The wireless clients can only use WPA-PSK security mode to connect to the
wireless network.
 WPA2-PSK: The wireless clients can only use WPA2-PSK security mode to connect to the
wireless network.
 WPA/WPA2-PSK Mixed: The wireless clients can use WPA-PSK or WPA2-PSK security
mode to connect to the wireless network.
WiFi Password
It specifies the wireless password of the wireless network. To secure the wireless network,
you’d better set a password for your wireless network.
Changing WiFi Name and WiFi Password
Step 1 Choose Wireless Settings to enter the page.

Tenda F9 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	40 MHz
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	600 Mbit/s
Product type	Tabletop router
Product color	White
LED indicators	System, WAN, WLAN, WPS
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	-95 dBm, -74 dBm, -72 dBm, -62 dBm, -70 dBm, -73 dBm, -86 dBm, -90 dBm
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	21.5 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)	17.5 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	15 dBmW
Ethernet LAN (RJ-45) ports	4
Flash memory	2 MB
Internal memory	16 MB
Processor model	Realtek
Output current	1 A
Output voltage	9 V
Power source type	DC
Power consumption (typical)	1.98 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Frequency band	2.4 - 2.4835 GHz
Antenna gain level (max)	6 dBi
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Browser supported	Internet Explorer 5.0, Firefox 1.0
Windows operating systems supported	Windows 2000
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	171.3 mm
Height	36.4 mm
