Electrical Set Up
Before beginning the wiring process turn off the circuit breaker so that no power
is connected to the controller. ThermoSpas recommends all spa wiring to be
done by a licensed electrician. Improper wiring may void your warranty. Incorrect
or incomplete wiring will very likely create a dangerous hazard. Performing a
conversion or any other modication to the original hardware or installation
conguration mandates that the owner assumes full responsibility for assuring
that the resulting system complies with all applicable national, state, and local
wiring codes and ordinances for the location of the unit. Be aware that there are
major differences in wiring codes if this unit is to be installed at any location other
than a private residence.
The Safe Electrical Hook-up of Your Spa
• The electrical installation of your spa must be done by a qualied electrician in accordance
with the National Electrical Code (NEC), and all local codes effective at the time of installation.
• Your spa must be installed on a dedicated electrical circuit. No other appliances or electrical
equipment may be used on this circuit.
!
WARNING: If your spa is not installed in accordance with the NEC, it may create a danger-
ous safety hazard. Improper electrical installation may also damage the inner workings of a spa
and void your warranty.
!
WARNING: If your electrician is not absolutely sure how to correctly connect your system,
call the ThermoSpas Technical Service Department at 800.876.0158, option 2. Mistakes may be
costly and will invalidate your equipment warranty.
Before beginning the wiring process turn off the circuit breaker so that no power is connected
to the controller. ThermoSpas recommends all spa wiring to be done by a licensed electrician.
Improper wiring may void your warranty.
Electrical Service Requirements
Before wiring for a spa, one of the rst considerations is whether or not your main service or
sub-panel feeding your spa has the capacity to provide sufcient power to your spa. A licensed
electrician will be able to perform a load calculation to determine this.
Select the inlet you want to use, drill a hole large enough for the wires on the skirt panel and
then feed the power cable through to the control box. To allow access you will have to trim/cut
the ThermoFoil blanket under the skirt. For access from underneath the spa, please contact the
Service Department for help (800.876.0158).
DANGER
Turn power off
before servicing. This
task should only be
performed by a quali-
fied technician.
!
RISK OF SHOCK OR
ELECTROCUTION!
RED
BLK
WHT
TB1
CONTROL BOX
General location
of the spa pack.
Location varies by
model.
Electrical Set Up
