ThermoSpas Designer Series User Manual

25
Standard-In-Economy Mode
Allows you to temporarily change the mode to Standard while in Economy mode. This would
allow the heater to run for one hour to heat the spa. Once the hour is up the spa will revert back
to Economy mode and the spa will heat only during the preset ltration cycles. Heating will occur
until the water reaches the next highest degree about the temperature set-point. Both the Stan-
dard (STANDARD) and Economy (ECONOMY) icon will be displayed. To activate this mode:
1. The spa must be in economy mode.
2. While in economy mode, press the Jets Pump 1 ( ) button.
3. For the next hour the spa will run in Standard-In-Economy mode allowing the heater to
activate.
4. To exit this mode, during the hour, press the Mode/Prog ( ) button. If not, after the hour
is up the spa will revert back to economy mode.
Sleep Mode
Heats the spa to within 20° of the temperature set-point, but only during ltration cycles. The
Sleep icon will be displayed unless the mode is changed. To activate this mode:
1. Press the Mode/Prog ( ) button to enter the mode programming.
2. Press the Cool ( ) button to scroll through the mode settings: STANDARD, ECONOMY
and SLEEP.
3. The current mode will ash on the LCD screen until a selection is conrmed and
programmed.
4. Once the Sleep mode is displayed on the LCD screen, press the Mode/Prog ( ) button
to conrm and exit the menu.
5. The “SLEEP” icon will be constantly displayed on the LCD screen as an indication of the
mode the spa is currently set to.
Standby Mode
Use the Standby Mode to temporarily shut off all spa functions. This mode can be used to when
replacing the lters or when the lters need to be cleaned. This mode last for 1 hour. To activate
this mode:
1. Press the Cool ( ) button.
2. Press the Jets Pump 2 ( ) button.
3. The LCD screen will display “Sby” to indicate that the spa is in standby mode.
4. To resume normal operation, press any Control Panel button (except Jets pump 1) or for the
hour to expire.
Economy Mode Heating Cycles
Six minutes after power-up, the spa will begin its rst heating cycle. The second cycle will occur
12 hours later. During each lter cycle, the circulation pump, heater and ozone will turn on. The
plumbing lines will also be purged. Although the circulation pump is set to run for 24 hours, the
lter cycles can still be programmed. This allows the lines to purge or allow the spa to heat when
set in economy mode. To program the heating cycles:
1. Press the Time ( ) button.
2. Press the Mode/Prog ( ) button three times. Must be done within three seconds of
pressing the Time button. The LCD screen will display “Program,” “Filter 1” and “Start Time,”
respectively.
3. Press the Warm ( ) or Cool ( ) button to adjust the hour start time in increments of
one hour.
4. Once the time you selected is displayed, press the Mode/Prog ( ) button to conrm your
selection.
Programming Instructions
