B.Usethejamnuttocompressanyspringthat
measuregreaterthan1.56inches.
Figure8
1.Boomhingespring2.Jamnut
4.Repeattheprocedureforeachspringonbothboom
hinges.
5.Movetheboomsintothetransport“X”position.
SeeOperatingtheBoomsintheOperationsection
formoreinformation.
4
AdjustingtheBoomstoLevel
NoPartsRequired
Procedure
1.Attheoperator’sposition,turntheignitionkeyto
Ontoenergizethesystem.
2.Movetheboomsintopositionsothattheyarelevel
withtheground.
3.Removethekeyandexittheoperator’sposition.
4.Atthehinge,adjustthepositionofthebumpersso
theboomcannotmovepastlevelwiththeground.
Takecaretomakesurethebumperislevel.
5.Tightentheboltandnuttolockthebumpersintothe
adjustedposition.Torquethefastenersto135-165
ft-lbs(183-223N-m).
Note:Thebumpermayexperiencesomecompression
overtime.Iftheboomsdropbelowlevel,usethis
proceduretoreadjustthebumperpositionneeded.
5
CompletingtheSetup:
Learningmoreaboutyour
product.
Partsneededforthisprocedure:
1Ignitionkey
1
Operator’sManual
1
EngineOperator’sManual
1
PartsCatalog
1
OperatorTrainingMaterial
1
RegistrationCard
1
Pre-deliveryInspectionSheet
Procedure
1.Readthemanuals.
2.ViewtheOperatortrainingmaterial.
3.CompletetheregistrationcardandreturntoToro.
4.Storethedocumentationinasafeplace.
